Part outline
Construction
Ferrite Core, 8 Pin Horizontal Bobbin
Configuration · 8P · Horizontal
Versatile EE1605 transformer with 8-pin horizontal configuration, allowing for multiple output windings and complex circuit designs.
The core decides everything else
Published figures describe the standard build. Every part is wound to order — send your exact requirement and we will confirm the specification on the quotation.
EE, EI, EER, ETD, EFD, PQ and RM core ferrite transformers for switch-mode power supplies, converters and inverters. Wound to your turns ratio, inductance and isolation requirements.
Start a project
Send your inductance, turns ratio, current rating and mechanical envelope — we will come back with a design and a price.
